A 3D render of a yellow industrial check valve. The valve has "VELAN" and "800" embossed on the front along with the number "1". It features a robust, rectangular top with two raised bolt-like structures for secure sealing.

API 602 Hydrofluoric Acid Alkylation Check Valve

Product Line
  • Small forged valves gate, globe, and check valves
Product Type
  • Check

Features & Benefits

  • Available designs: spring actuated piston and ball, and swing check.
  • Bonnet joint is precision machined and has a special surface finish for extended service life.
  • Fully encapsulated gasket design with metal-to-metal body to bonnet contact for optimal and controlled gasket compression.
  • Wide variety of end connections as per client’s needs: flanged, BW, SW, NPT, weld stubs, including other types.
  • Swing check non-rotating disc is fastened securely to disc hanger with a lock nut and cotter pin. All parts are accessible from top for easy servicing.
  • Cage unit design with no body penetration by hinge pin.
  • HF acid detecting paint allows for an immediate visual detection when exposed to acid or acid vapors to ensure valve integrity.

Product Details

SpecDetail
Size RangeNPS 1/2 - 2 (DN 15 - 50)
Pressure ClassASME classes 150 - 800
Standard ConnectionsThreaded, Socket weld, Flanged, Butt weld
