Bolted Bonnet Forged Bellows Seal Globe Valve

Product Line
  • Large forged bolted bonnet nuclear valves
Product Type
  • Globe

Features & Benefits

  • Long cycle life bellows (3000 cycles) in Gr. 321 (stainless) or Inconel. Designed and successfully tested in high pressure/temperature conditions.
  • Two-part bellows.
  • Two secondary stem seals: a) Backseat in open position; b) Graphite packing.
  • Low torque due to: a) Non-rotating stem prevents torsion of bellows; b) Stem nut thrust bearings; c) Central lubrication.
  • Bellows monitoring port (optional): A plug can be connected to the space above the bellows to monitor performance.
  • Forged for higher safety: Increased toughness, strength and fatigue resistance
  • Guided disc: Seat and disc hardfaced with CoCr alloy, ground and lapped.

Product Details

SpecDetail
Size RangeNPS 2 1/2 - 10 (DN 65 - 250)
Pressure ClassASME class 600 - 1500
Standard ConnectionsButt weld
