Bolted Bonnet Forged Flexible Wedge Gate Valve

Product Line

Large forged bolted bonnet valves

Product Type

Gate

Features & Benefits

Velan bolted bonnet flexible wedge gate valves are ideal for high pressure steam, catalytic reformers, hydrocrackers and other tough services.

Stronger, leakproof bolted body bonnet joint ensures joint tightness with a higher bolting torque.
Wedge guiding minimizes seat rubbing and scuffing resulting in long cycle life.
Designed to ASME B16.34.
Body made of superior strength forgings and optional cast steel.
Velan stem seal offers tight seal with little to no maintenance over long periods of time.
Optional live-loading of packing and leakoff.
Non-rotating stem.
Hardfaced seating faces resist erosion.
Available with provision for seal weld.
Other sizes and pressure classes available. Contact the company for specifications.

Product Details

Spec	Detail
Size Range	NPS 2 - 24 (DN 50 - 600)
Pressure Class	ASME Classes 150 - 1500
Standard Connections	Socket weld, Butt weld
