A metallic gate valve with a blue handwheel, designed for industrial use, is shown against a white background. The word "NUCLEAR" appears in a blue box at the bottom right corner, indicating its application.

Forged Steel Extended Body Gate Valves for Nuclear Applications

Product Line
  • Small forged valves
Product Type
  • Gate

Features & Benefits

Available for nuclear class 1, 2, and 3 and safety related applications.

Design features

  • Complies to ASME B16.34 standards.
  • Available with an extended body or an integrally reinforced extended body (IREB).
  • Extended body gate valves have a welded or NPT connection and are used for tapping of pressure vessels and header lines for vents, drains or takeoff lines and instrumentation.
  • Also available with extended body assemblies for vents, drains, and instrument root valves.

Product Details

SpecDetail
Size RangeNPS 1/2 - 2 (DN 15 - 50)
Pressure ClassASME classes 800 - 1500
Standard ConnectionsThreaded, Socket weld

Quality That Lasts

Precision Engineered

Our products, crafted with cutting-edge precision, set the industry standard for quality, reliability, and versatility across an expansive range of applications.

Long-Lasting & Durable

Velan leverages advanced engineering capabilities and innovation to create durable valves that meet critical industrial needs in the areas of nuclear power, mining, oil and gas, and more.

Certified & Tested

Innovation is our DNA. From our first steam trap to advanced cutting-edge valve designs, we are committed to providing solutions that define the highest standards of quality and performance.
