BPU series fully welded side-entry trunnion ball valves

Product Line
  • API 6A and 6D ball valves
Product Type
  • Ball

Features & Benefits

Velan ABV offers a complete range of fully welded two or three-piece side-entry ball valves. The fully welded body construction provides a lighter solution while also avoiding potential leak paths to the external environment, ensuring reliable protection of the whole system. A solid double trunnion configuration and two independent seats with bidirectional sealing ensure the greatest level of tightness and reliability under high pressure and temperature conditions in all critical isolation services. Several unique features are available offering advanced technical solutions suitable for sweet or acid gas processes or pipelines applications. Material selection is fully customizable to meet customers project specifications.

Seat design

  • Soft or metal seated with hard facing on Ball and Seats
  • Self relieving seats
  • Double piston seats

Features

  • Double block and bleed design (DBB)
  • Secondary seals in pure Graphite
  • Anti-static device
  • Anti-blowout stem
  • Emergency sealant injection on seats and stem available
  • Low fugitive emission stem packing available
  • CRA overlay on all dynamic sealing areas or on all wetted parts available
  • Stem extension for underground installations

Operator

  • Manual: wrench or gear with padlocking
  • Actuated: Pneumatic/ Hydraulic/Electric

Testing & certifications

  • Compliance with API 6D & ISO 5208 & API 598 inspection and testing
  • Fire safe and fire tested as per API 6FA/607
  • SIL 3 Certification as per IEC61508
  • Fugitive Emission as per ISO15848
  • PED 2014/68/UE

Product Details

Spec Detail
Size Range NPS 2-56 (DN 50-1400)
Pressure Class ASME 150 - ASME 2500
Standard Connections Flanged (RF, RTJ) as per B16.5 &B16.47, Butt Welded as per B16.25
Series BPU
Valve design based on API 6D and customer requirements
Temperature range -150 to 428°F (-101 to 220°C)
Face-to-face As per API 6D standard
End connections RF, RTJ as per B16.5 &B16.47
BW, Butt Welded as per B16.25
Body design Forged welded two-piece and three-piece
