Cast Steel Bellows Seal Bolted Bonnet Gate Valves for Nuclear Applications

Product Line

Cast steel gate, globe, and check valves

Product Type

Gate

Features & Benefits

Available for nuclear class 1, 2, and 3 and safety related applications.

Design features

Long cycle life bellows (2000 cycles) in Gr. 321 (stainless), or lnconel.
Improved body-bonnet joint. Graphite reinforced with SS foil gasket for Class 150 valves. Fully-encased, spiral wound graphite-filled Gr. 316 (stainless) gasket for Classes 300-600.
Bolted body-bonnet for fast serviceability. Hermetically sealed bonnets available for Classes 300 and 600.
Two or three section bellows assembly.
Non-rotating stem prevents torsion of bellows.
Two secondary stem seals:
a) Backseat in open position; and
b) Graphite packing.
Welded-in seat hardfaced with Stellite 6.
Wedge hardfaced with Stellite 6 for long life.
Seating faces hardfaced with Stellite 6, ground and lapped.

Product Details

Spec	Detail
Size Range	NPS 2 - 12 (DN 50 - 300)
Pressure Class	ASME classes 150-600
Standard Connections	Flanged or Butt weld
