Memoryseal® TE-150/300/600 Resilient-Seated Ball Valve

Product Line

Memoryseal® and resilient-seated ball valves

Product Type

Ball

Features & Benefits

Velan Memoryseal™ top-entry resilient-seated ball valves can be easily serviced or replaced in-line while the integrity of the valve is not affected. The exclusive Memoryseal™ seats compensate automatically for wear and fluctuations of pressure and temperature. Standard valves with MPTFE seats and graphite packing can handle steam service up to 250 psig (17.2 bar). Valves with carbon graphite filled seats are suitable for steam up to 450 psig (31 bar). These rugged, versatile, resilient-seated ball valves can meet NACE specifications.

Memoryseal™ top-entry ball valves are compliant with API 608 and dual qualified to API 641 and ISO 15848-1 fugitive emissions standards.

Product Details

Spec	Detail
Size Range	NPS 1/2 - 4 (DN 15 - 100)
Pressure Class	ASME Classes 150 - 600
Standard Connections	Flanged, Threaded, Socket weld, Butt weld
