Features & Benefits
Check valves are installed to allow flow in one direction only and they protect systems that can be affected by reverse flow, such as a system shutdown. They are operated entirely by reaction to the flow and therefore do not require external actuation. Care and attention should be paid to check valve installation orientation. For information please consult the appropriate Installation Operation manual (IOM).
- Stronger, leakproof bolted body bonnet joint.
- No penetration of hinge pin to outside eliminates pin seal leakage and provides in-line service.
- Compact cage unit. All moving parts are attached to the hanger block/hanger ring and can be removed easily for service.
- Forged seat/disc (1) is hardfaced with CoCr alloy, ground and lapped to a mirror finish for maximum erosion resistance and long service life. The seat is seal-welded to the body. A cast option is also available.
- Disc can partially adjust for tight shutoff. In the fully open position, it rests against a stop.
- CoCr alloy bearings for hinge pin.
- Easy in-line service. All parts are easily accessible for maintenance. Seating faces can be re-lapped.
- Forged cover
Product Details
Spec | Detail |
---|---|
Size Range | NPS 2 1/2 - 24 (DN 65 - 600) |
Pressure Class | ASME Classes 150 - 1500 |
Standard Connections | Butt weld, Flanged |
Quality That Lasts
Precision Engineered
Our products, crafted with cutting-edge precision, set the industry standard for quality, reliability, and versatility across an expansive range of applications.
Long-Lasting & Durable
Velan leverages advanced engineering capabilities and innovation to create durable valves that meet critical industrial needs in the areas of nuclear power, mining, oil and gas, and more.
Certified & Tested
Innovation is our DNA. From our first steam trap to advanced cutting-edge valve designs, we are committed to providing solutions that define the highest standards of quality and performance.
Related Documents
